Nitrogen Always Available
On-site nitrogen generation ensures a continuous supply without dependence on external suppliers or delivery logistics.
INMATEC PN Series – Standard
High-purity to ultra-high-purity nitrogen generated directly on site using integrated PSA technology, continuous process monitoring, and remote system management.
Key Specifications
| Technology: PSA (Pressure Swing Adsorption) |
| Nitrogen Capacity: 0.85–1,250 Nm³/h |
| Nitrogen Purity: 95% to 99.999% (Grade 5.0) |
| Residual O₂: Up to 10 ppm (depending on settings) |
Key Specifications
| Technology: PSA (Pressure Swing Adsorption) |
| Nitrogen Capacity: 0.85–1,250 Nm³/h |
| Nitrogen Purity: 95% to 99.999% (Grade 5.0) |
| Residual O₂: Up to 10 ppm (depending on settings) |
- Multilingual Touchscreen ControllerAn intuitive multilingual touchscreen with integrated nitrogen concentration monitoring enables easy control and operation of the entire system.
- Stainless Steel Valve TechnologyLow-maintenance stainless steel valves provide long service life, high reliability, and stable PSA system performance.
- Carbon Molecular SieveHigh-quality, long-life carbon molecular sieves ensure efficient gas separation and stable nitrogen production throughout the service life of the system.
- Inlet & Outlet FiltrationMulti-stage inlet and outlet filtration protects the PSA system, extends component life, and ensures consistently high nitrogen quality.
- Long-Term Data StorageAutomatic operating data logging and archiving provide complete traceability, performance analysis, and production process optimization.
| Parameter | PN 20 | PN 30 | PN 40 | PN 60 | PN 90 | PN 150 | PN 220 | PN 270 | PN 350 | PN 500 | PN 750 | PN 1000 | PN 1500 | PN 2000 | PN 2500 | PN 3000 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity [Nm³/h] | 10.80 | 16.50 | 20.80 | 31.20 | 49.20 | 84.00 | 105.00 | 141.00 | 211.00 | 260.00 | 372.00 | 440.00 | 630.00 | 860.00 | 1050.00 | 1250.00 |
| Grade | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Residual O₂ [ppm] | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 | 10.000 |
Why Choose the INMATEC PN Series – Standard?
Low Operating Costs
Generating nitrogen on site significantly reduces costs compared to cylinders, bundles, or liquid nitrogen.
Proven PSA Technology
The fully integrated PSA system ensures reliable performance while continuously monitoring all key operating parameters.
Adjustable Nitrogen Purity
Nitrogen purity can be adjusted from 95% to 99.999%, providing the optimal solution for a wide range of industrial applications.
No Cylinder or Tank Rental
Eliminate rental costs, transportation expenses, and long-term gas supply contracts while gaining complete control over your nitrogen supply.
Reduced Environmental Impact
On-site nitrogen generation reduces gas transportation, lowers CO₂ emissions, and supports more sustainable, energy-efficient operations.
Food Industry
MAP & InertingNitrogen is used for modified atmosphere packaging (MAP), tank inerting, and extending product shelf life. The PN Series provides reliable on-site nitrogen generation for food processing applications.
Chemical & Pharmaceutical Industry
High PurityReliable nitrogen generation for process inerting, protection of sensitive products, and operation in hazardous environments.
Plastics Industry
Process StabilityNitrogen improves product quality during injection molding, blow molding, and other manufacturing processes while enhancing process stability.
Electronics
Component ProtectionAn inert atmosphere during soldering and electronic component manufacturing reduces oxidation and ensures consistently high product quality.
Metal Processing
Heat TreatmentNitrogen is used in heat treatment, laser cutting, and other processes where it prevents oxidation and improves surface quality.
Logistics & Storage
Product ProtectionNitrogen protects products against oxidation, moisture, and spoilage during storage while extending product shelf life.
Wine & Beverage Industry
InertingNitrogen prevents oxidation of wine and beverages, enables tank inerting, and ensures filling processes without compromising product quality.
Oil & Gas
Process SafetyNitrogen is used for pipeline inerting, pressure testing, prevention of explosive atmospheres, and the safe maintenance of process systems.
Laser Cutting
Clean CutsAs a shielding gas for laser cutting, nitrogen prevents oxidation, produces clean cutting edges, and minimizes the need for secondary finishing.
Nitrogen and oxygen generators
Tell us your requirements and we will propose the right configuration.
Fill in the short form and we will prepare a generator proposal based on flow rate, purity, pressure, and operating mode. If needed, we also include dryer, filtration, and storage tank.
Sizing based on flow rate, pressure, and required purity
Proposal of filtration, drying, and storage tank for stable gas supply
Delivery, installation, commissioning, and service
