High performance and stable operation
The reliable characteristic enables constant pressure up to 1.5 bar in continuous operation and up to 2.2 bar in intermittent mode.
Elmo Rietschle V-DTA
Dry-running rotary vane compressor for industrial applications requiring high flow, stable pressure and quiet operation.
| Volumetric flow: 58 to 88 m³/h |
| Max. overpressure: Up to 1.5 bar |
| Intermittent pressure: Up to 2.2 bar |
| Configuration: Dry-running rotary vane compressor |
| Volumetric flow: 58 to 88 m³/h |
| Max. overpressure: Up to 1.5 bar |
| Intermittent pressure: Up to 2.2 bar |
| Configuration: Dry-running rotary vane compressor |
- Dry-running rotary vane designOperation without oil in the compression chamber provides clean operation, less maintenance and reliability in industrial applications.
- Rotor bearings on both sidesThe stable mechanical construction with bearings on both sides of the rotor enables a long service life and smooth operation.
- Flanged motor with torsionally flexible couplingReliable power transmission with minimal vibration, optimized for continuous industrial operation.
- Acoustic enclosure with optimized coolingThe integrated enclosure reduces noise and directs cooling air for effective heat dissipation.
- Continuous operationDesigned for continuous operation at overpressure up to 1.5 bar and a stable characteristic across the full operating range.
| Parameter | 60 | 80 |
|---|---|---|
| Volumetric flow [m³/h] | 58 | 73 |
| Overpressure [bar] | 0,7 / 1,5 | 0,9 / 1,5 |
| Motor version | 3~ | |
| Motor supply | 230 – 400 V ± 10 % | 230 – 400 V ± 10 % |
| Motor power [kW] | 2,2 / 3,0 | 3,0 / 4,0 |
| Current [A] | 10,0 / 5,9 | 11,4 / 6,6 | 12,2 / 7,1 | 15,0 / 8,8 |
| Rotational speed [min⁻¹] | 1450 / 1740 | |
| Average noise level [dB(A)] | 72 | 74 |
| Max. weight [kg] | 86 / 90 | 97 / 105 |
Benefits
Quiet and efficient operation
The optimized construction and acoustic protection ensure low noise and efficient cooling, even under demanding operating conditions.
Robust industrial design
A rotor supported on both sides and a flanged motor with a reliable coupling ensure a long service life and stable operation.
Optimized cooling
Directed cooling air through the acoustic enclosure enables effective heat dissipation and reliable operation at higher temperatures.
Easy operation and servicing
The construction provides easy access to key components, simplifying maintenance and reducing service time.
General industry
IndustryReliable overpressure generation for industrial processes such as air blowing, drying and material transport.
Packaging industry
PackagingUsed for air blowing, product transport and pneumatic systems in packaging lines.
Pneumatic conveying
TransportAn ideal solution for conveying bulk materials with stable overpressure and constant airflow.
Environmental technology
EnvironmentSuitable for aeration and other processes requiring a stable air supply in treatment and environmental systems.
Food industry
Food processingUsed in processes requiring overpressure for transport, packaging or product handling.
